Chema XPS
Chema XPS Boards are extruded polystyrene foam insulation panels available in four performance levels — Basic, Standard, Pro, and Advanced — engineered to provide exceptional thermal insulation, energy efficiency, and structural durability. Each type offers specific compressive strength and density values to suit diverse building requirements, from residential applications to heavy-duty industrial roofing.
Category Polystyrene Foam Materials
Chema XPS is a high-performance extruded polystyrene insulation boards for roofs and walls, available in four grades — Basic, Standard, Pro, and Advanced — offering lightweight, water-resistant, and thermally efficient performance that saves up to 40 % in energy costs.
Properties
• Lightweight and easy to handle and install
• High compressive and flexural strength
• Excellent thermal insulation (closed-cell structure)
• Water and vapor resistant
• Long-term dimensional stability
• Zero ozone depletion potential
• GREENGUARD certified for low emissions
• EnergyStar® compliant
• Saves up to 40 % of energy consumption
• Suitable for exposed or buried insulation systems
Areas of Use
• Thermal insulation for roofs, walls, and foundations
• Under-slab and floor insulation
• Cold storage facilities and refrigerated rooms
• Concrete sandwich panels
• Waterproofing protection layers
• Industrial and commercial building insulation
Types
| Property | Unit | ASTM Test | Chema BASIC | Chema STANDARD | Chema PRO | Chema ADVANCED |
|---|---|---|---|---|---|---|
| Density | kg/m³ | D1622 | 28 ± 2 | 30–32 | 32–36 | 36–40 |
| Compressive Strength | kPa | D1621 | 200–250 | 250–350 | 300–350 | 350–450 |
| Flexural Strength (min.) | kPa | C203 | 400 | 450 | 500 | 550 |
| Oxygen Index (min.) | % | D2863 | 24 | 24 | 24 | 24 |
| Water Absorption | % (Vol.) | C272 | 0.30 | 0.27 | 0.30 | 0.20 |
| Dimensional Stability | % | D696 | 0.5 | 0.5 | 0.5 | 0.5 |
| Thermal Conductivity | W/m·°C | C518 | 0.030 | 0.033 | 0.033 | 0.033 |
| Thermal Resistance (R-value) | K·m²/W | C518 | (R-5.0) 0.88 | (R-5.0) 0.88 | (R-5.0) 0.88 | (R-5.0) 0.88 |
| Water Vapor Performance (max.) | g/h·m² | E96 | 63 (1.1) | 63 (1.1) | 63 (1.1) | 63 (1.1) |
| Max. Service Temperature | °C | – | 50 | 50 | 50 | 50 |
Storage & Shelf life
• Store panels in a covered, ventilated area away from direct sunlight and heat sources.
• Avoid stacking on edges or near sparks/flames.
• Panels must be covered within 24 hours after installation to prevent UV exposure.
• Indefinite shelf life under proper storage conditions.
Packaging
• Supplied in various thicknesses and sheet sizes according to project requirements.
• Each type is color-coded and labeled for identification (Basic / Standard / Pro / Advanced).
Application
• To begin with installation timing, it’s best to install panels in the early morning or before sunset. This is because it helps avoid exposing them to strong, direct sunlight.
• Following this same principle of managing heat, if the installation surface (concrete or membrane) is too hot, it must be cooled first by spraying water.
• Finishing: After installing the panels, it is important to proceed immediately with the finishing step in order to protect them from direct sunlight. Therefore, the panels should be covered with a light cement layer, which serves as the final protective finish.
• Finally, and most importantly, do not leave panels uncovered for more than 24 hours, as this will prevent damage from prolonged ultraviolet light exposure.
