Chema XBoard insulation panel featuring a blue foam core with a textured gray surface layer, designed for waterproofing and thermal insulation applications

Chema XBoard

Chema XBoard panels are easy-to-finish thermal insulation solutions designed for both interior and exterior use. These panels are engineered for superior heat, water, and sound insulation. The core of each panel is made from Blue Foam, a type of Extruded Polystyrene (XPS), which is then reinforced with a fiberglass mesh and treated on both sides with a special polymer-modified cementitious layer. This composite structure makes the panels not only excellent insulators that contribute to saving electricity consumption but also highly resistant to water and moisture absorption. Furthermore, they are designed for convenience, being easy to apply, cut, and handle during transportation and installation.

Category      Polystyrene Foam Materials

Facebook
LinkedIn
WhatsApp

Chema XBoard is a high-performance heat, water, and sound insulation panel for interior and exterior applications. It is constructed from an Extruded Polystyrene (XPS) foam core, reinforced with fiberglass mesh, and coated with a polymer-modified cementitious layer on both sides. This makes it an ideal, easy-to-use solution for insulating walls, bathrooms, and cooling rooms.

Properties

Dimensional stability 01 1024x1024

dimensional stability

Easy cut 01 1024x1024

easy cut

Easy cutting 01 1024x1024

easy cutting

Easy to apply 01 1024x1024

easy to apply

Easy use 01 1024x1024

easy use

Made of Extruded Polystyrene 01 1024x1024

Made of Extruded Polystyrene

Reinforced with fiberglass mesh 01 1024x1024

Reinforced with fiberglass mesh

02 Resistance to moisture 01 1024x1024

Resistance to moisture

Saves electricity consumption 01 1024x1024

Resistance to moisture

Soundproof 01 1024x1024

soundproof

Special polymer modified cementitious layer on both sides 01 1024x1024

special polymer-modified cementitious layer on both sides

04 Excellent adhesion properties 01 1024x1024

strong adhesion

04 thermal insulation 01 1024x1024

thermal insulation

Areas of Use

Bathrooms 01 1024x1024

Moist environments such as bathrooms, kitchens, swimming pools, etc

Constructing partitions 01 1024x1024

Constructing partitions and lightweight walls inside rooms and halls

Ceilings 01 1024x1024

Thermal and moisture insulation for ceilings, floors, and walls

02 Swimming pools 01 1024x1024

Swimming pools

Decorative elements 01 1024x1024

Decorative elements for both straight and curved designs

Facades 01 1024x1024

Cladding of external façades and internal walls

Fixed tiles 01 1024x1024

Fixing tiles and applying all types of finishes and paints

Interior walls 01 1024x1024

interior walls

Kitchens 01 1024x1024

 kitchens







Installation Tips

CHEMA XBOARD is installed on flat surfaces such as concrete, brick, wood, or metal frames
using:
• A thin layer of adhesive (CHEMA ADHESIVE 102)
• Mechanical fasteners such as screws and anchors
• Additional mechanical fixation can be used if needed
• Joints are treated using joint filler and waterproof sealing tape

Technical Specifications of XPS Core

PropertyValueTest Method
Density32–33 kg/m³ASTM D1622
Compressive Strength300 kPaASTM D1621
Water Absorption0.2% (V/V)ASTM C272
Thermal Conductivity0.025 W/m·KASTM C518
Fire ClassificationClass B2DIN 4102

Technical Specifications of Chema XBoard

Thickness (mm)Width (mm)Length (mm)Weight (kg/board)Thermal Transmittance (W/m²·K)
25600240081.276
3560024008.50.917
556002400100.587
75600240011.20.476

 Packaging & Storage
• Boards are wrapped and packed on pallets for transport
• Should be stored flat, in a dry location, away from direct sunlight and moisture
