Chema EPS
CHEMA EPS is a versatile expanded polystyrene (EPS) foam board designed for multiple construction applications. It serves as a high-performance solution for thermal and acoustic insulation, a flexible filler for expansion joints, and is ideal for void filling and wall thermal insulation. A primary benefit of using CHEMA WHITE FOAM is its significant impact on energy efficiency, enabling electricity power savings of up to 40%. The material is exceptionally light weight, which makes it easy to handle during both transportation and on-site installation. By providing excellent thermal insulation, it reduces overall electricity consumption and allows for the use of lower wattage air conditioning systems.
Category Polystyrene Foam Materials
Chema EPS is one of Chema Foam‘s products it’s a lightweight expanded polystyrene (EPS) foam board used for thermal and acoustic insulation, expansion joints, and void filling. It has different densitys for differenct uses startign from 10 till 35. Its key advantage is the ability to save up to 40% electricity consumption by providing effective thermal insulation. It is easy to transport and install.
Key Features & Benefits
• It provides effective thermal and acoustic insulation.
• It saves up to 40% in electricity power.
• Lightweight, making it easy to handle during transportation and installation.
• It reduces electricity consumption and allows for the use of low wattage air conditioners.
• When used in walls, it eliminates thermal joints between bricks and partially eliminates them with beams and columns.
• It is classified according to the ASTM C578 specification.
Areas of Use
• Wall thermal insulation.
• General thermal and acoustic insulation.
• As a flexible expansion joint.
• Void filling.
Installation Method
1. Build two parallel solid brick walls.
2. Install CHEMA WHITE sheets between the brick walls.
3. Finish the walls.
Technical Data
| Description | S. Specification | Unit | 10 Kg/m³ | 12 Kg/m³ | 15 Kg/m³ | 20 Kg/m³ | 25 Kg/m³ | 30 Kg/m³ | 35 Kg/m³ | ||
| Thermal resistance* | ASTM C518 | R-VALUE | 3.0 | 3.4 | 3.6 | 3.8 | 4.0 | 4.2 | 5.0 | ||
| Water absorption | ASTM C272 | % | 6.0 | 5.0 | 4.0 | 3.0 | 3.0 | 2.0 | 1.5 | ||
| Compressive strength** | ASTM D 1621-73 | KPa | 58 | 62 | 70 | 90 | 105 | 175 | 220 | ||
| Flame Spread | ASTM E84 | Class B | < 75 | < 75 | < 75 | < 75 | < 75 | < 75 | < 75 | ||
| Smoke Development | ASTM E84 | Class B | < 450 | < 450 | < 450 | < 450 | < 450 | < 450 | < 450 | ||
| All values are per inch. | |||||||||||
| Note: 1 Kpa=0.01 ton/m2. |
Safety Precautions
• Its boards are breakable.
• Keep the product away from sparks and flame.
• Avoid contact with strong oxidizing agents and aromatic solvents.
• Avoid stacking the product on its edge.
